CHI TIẾT SẢN PHẨM
SK 3328504 Máy lạnh tủ điện Rittal , Nema 4X, công suất làm lạnh 2.200 W
Máy lạnh tủ điện 3328504 (máy làm mát tủ điện 3328504) công suất làm lạnh 2.200...
-
3328504
-
Liên hệ
-
0
- Thông tin chung
- Tài liệu kỹ thuật
- Ứng dụng
- Lỗi thường gặp
- Hướng dẫn sử dụng
- Video
| Article number | SK 3328.504 |
| Description | Energy-efficient Blue e wall-mounted cooling units with e-Comfort controller integrated as standard, RiNano coating on the condenser and electrical condensate evaporation. Protection category NEMA 4X. |
| Benefits | May be linked with the IoT interface via Blue e IoT adaptor for cooling units with e-Comfort controller |
| Material | Stainless steel 1.4404 (AISI 316L) |
| Protection category IP to IEC 60 529 | External circuit IP 34 |
| Internal circuit IP 55 | |
| Protection category NEMA | NEMA 4X |
| Supply includes | Nano-coated condenser |
| Fully wired ready for connection (plug-in terminal strip) | |
| Drilling template | |
| Assembly parts | |
| Integral electric condensate evaporation | |
| Variant | wall-mounted |
| Total cooling output to DIN EN 14511 | L 35 L 35 at 50 Hz: 2.1 kW |
| L 35 L 35 at 60 Hz: 2.44 kW | |
| L 35 L 50 at 50 Hz: 1.6 kW | |
| L 35 L 50 at 60 Hz: 1.85 kW | |
| Air throughput (unimpeded air flow) | External circuit: 980 m³/h |
| Internal circuit: 980 m³/h | |
| Rated operating voltage | 230 V, 1~, 50 Hz/60 Hz |
| Dimensions | Width: 405 mm |
| Height: 1,650 mm | |
| Depth: 388 mm | |
| Temperature control | e-Comfort controller (factory setting +35 °C) |
| Temperature range | Bearing: -40 °C...+70 °C |
| Operation (environment): +10 °C...+50 °C | |
| Setting range: +20 °C...+50 °C | |
| Refrigerant/cooling medium | Refrigerant: R134a |
| Quantity: 0.9 kg | |
| Global Warming Potential (GWP): 1,430 | |
| CO₂ equivalent (CO₂e): 1.29 t | |
| Power consumption P | L 35 L 35 at 50 Hz: 0.86 kW |
| L 35 L 35 at 60 Hz: 1.04 kW | |
| L 35 L 50 at 50 Hz: 1.02 kW | |
| L 35 L 50 at 60 Hz: 1.23 kW | |
| Rated current max. | At 50 Hz: 5.8 A |
| At 60 Hz: 6.8 A | |
| Start-up current max. | At 50 Hz: 20 A |
| At 60 Hz: 22 A | |
| Miniature circuit-breaker/fuse | 16 A |
| Permissible operating pressure (p. max.) | 28 bar |
| eCl@ss 8.0/8.1 | 27180704 |
| Energy efficiency ratio (EER) 50/60 Hz L35 L35 | 2,3 / 2,47 |
| Packs of | 1 pc(s) |
| Weight/pack | 80 kg |
